Samantha
A Rogue Rabbit of Elegance
The first Rogue Rabbit: A bicycle built in the classic style, with elegance and refined details.
This bicycle is named in memory of the long-lived rogue rabbit, Samantha, who was the embodiment of agile fluffiness with a gentle disposition:
2004–2013
Frame
The frame is built in the classic style: Road-racing geometry for a gentle disposition; minimalist lugs, cut-out bottom bracket shell, standard diameter tubes for that classic look; polished stainless steel fork crown, fork blade ends, seat stay caps, and stay ends for classic elegance and durability; and, straight fork blades, offset 7°, for a touch of modernity.
| Part | Description |
|---|---|
| Top tube: | Kaisei 017 - 25.4mm ø (.7/.4/.7), CrMo |
| Down tube: | Tange Prestige - 28.6mm ø (.8/.5/.8), CrMo |
| Seat tube: | True Temper S3 - 28.6mm ø (.7/.6), CrMo |
| Head tube: | Reynolds - 31.7mm ø (1.1), 304SS |
| Steerer: | Columbus Metax - 1.65/1.14x320mm 25.4mm ø, SS |
| Fork crown: | Long Shen - 7° offset, 25.4mm race seat, SS |
| Fork blades: | KVA - 30/17/12mm ø (1.1/.9), SS |
| Fork ends: | G.P. Wilson Super-light - 9mm, 17-4PH SS |
| Fork bottom eyes: | VDC custom, 304SS |
| Chain stays: | KVA - 22.2/14mm ø (.7/.9), SS |
| Dropouts/rear ends: | G.P. Wilson Super-light - 10mm, SS |
| Rear end bottom eyes: | VDC custom, 304SS |
| Seat stays: | KVA - 17/12.5mm ø (.7/.5), SS |
| Seat stay caps: | Aircraft Spruce - .9mm 5/8" ø section, SS |
| HT/TT lug: | Eisho Royal - 31.8/25.4mm, CrMo |
| HT/DT lug: | Eisho Royal - 31.8/28.6mm, CrMo |
| ST/TT lug - single/stoker: | Eisho Royal - 25.4/28.6mm, CrMo |
| Bottom bracket shell - standard: | Eisho Royal - 68mm, CrMo |
| Brake bridge: | machined, SS |
| Water bottle bosses: | M4, SS |
| Water bottle boss reinforcements: | VDC "gear", 304SS |
| Chain stay bridge: | 5/8" ø (.9), SS |
| Brake cable guide: | 1/4" ø (0.020")/3/16" ø (.035"), SS |
| Front dérailleur hanger: | Silva - braze-on, SS |
| Front dérailleur cable guide: | 1/8" ø (.015"), 304SS |
| Rear dérailleur cable guide: | 1/8" ø (.015"), 304SS |
Components
The frame is fitted with three generations of near-turn-of-the-millenium Dura-Ace components for performance and durability, except for the SRAM Red brakes and shift/brake levers, selected for availability. A canted, offset seatpost complements the offset fork.
| Part | Description |
|---|---|
| Headset | Cane Creek, "110", Al alloy - silver (1") |
| Stem | Nitto, Pearl, Al alloy - silver (95mm) |
| Handlebars | Nitto, B177, Al alloy - silver (44cm x26mm) |
| Handlebar tape | Walnut, sew-on, Leather - black |
| Handlebar ends | Nitto, Al alloy - silver |
| Seatpost | Thomson, Elite - set-back, Al alloy - silver (27.2mm) |
| Saddle | Selle Italia, SLK, Leather - black |
| Brakes | SRAM, Red, Al alloy - grey (47mm) |
| Brake levers | SRAM, Red, CF - Lilac pearl (black hoods) |
| Bottom bracket | Shimano, Dura-Ace BB-7700, Fe alloy - silver (Octalink) |
| Chain | Shimano, Dura-Ace CN-7801 (3/32") |
| Crankset | Shimano, Dura-Ace FC-7700, Al alloy - silver (180mm) |
| Chainwheel | Shimano, Dura-Ace, Al alloy - bronze (39,53t) |
| Chainwheel bolts | Shimano, Dura-Ace, Al alloy - silver (M5) |
| Pedals | Shimano, Dura-Ace PD-7810, Al alloy - silver |
| Shifters | SRAM, Red, CF - Lilac pearl (10-speed) |
| Shifter adapter | custom, ShiftWidgetª, SS - silver (Model SRSH) |
| Front drailleur | Shimano, Dura-Ace FD-7800, Al alloy - silver (braze-on) |
| Rear drailleur | Shimano, Dura-Ace RD-7800, Al alloy - silver |
| Front tire | Challenge, Parigi-Roubaix, Rubber - black (700c x 27c) |
| Front rim strip | Tufo, standard (adhesive) |
| Front rim | Wolber, Aspin, Al alloy - grey (700c x 20c) |
| Front spokes | Wheelsmith, stainless - silver (15/16ga) |
| Front hub | Shimano, Dura-Ace HB-7800, Al alloy - silver (low-flange) |
| Rear tire | Challenge, Parigi-Roubaix, Rubber - black (700c x 27c) |
| Rear rim strip | Tufo, standard (adhesive) |
| Rear rim | Wolber, Aspin, Al alloy - grey (700c x 20c) |
| Rear spokes | Wheelsmith, stainless - silver (15/16ga) |
| Rear hub | Shimano, Dura-Ace FH-7850, Al alloy - silver (low-flange) |
| Cassette | Shimano, Dura-Ace CS-7800 (12-25t) |
| Front tire | Compass, Chinook Pass, Rubber - black (700c x 28mm) |
| Front inner tube | Specialized, Presta valve (700c x 18c) |
| Front rim strip | 3M, PTFE - beige (700c x 13c) |
| Front rim | DT, RR 1.1, Al alloy - black (700c x 20c) |
| Front spokes | Wheelsmith, stainless - silver (14/15ga) |
| Front hub | Shimano, Dura-Ace HB-7800, Al alloy - silver (low-flange) |
| Rear tire | Compass, Chinook Pass, Rubber - black (700c x 28mm) |
| Rear inner tube | Specialized, Presta valve (700c x 18c) |
| Rear rim strip | 3M, PTFE - beige (700c x 13c) |
| Rear rim | DT, RR 1.1, Al alloy - black (700c x 20c) |
| Rear spokes | Wheelsmith, stainless - silver (14/15ga) |
| Rear hub | Shimano, Dura-Ace FH-7850, Al alloy - silver (low-flange) |
| Cassette | Shimano, Dura-Ace CS-7900 (12-25t) |
| Water bottle cage | Nitto, SS - silver |
| Water bottle | Specialized, Plastic - clear (24oz.) |
| Spare tire | Compass, Chinook Pass, Rubber - black (700c x 28mm) |
| Spare tube | Specialized, Presta valve (700c x 18c) |
| Fenders | Honjo Koken, Smooth, Al alloy - silver (35mm) |
| Bell | Velo-Orange, Japanese, Al alloy - silver |
| Computer | Planet Bike, Proteg 9.0, Plastic - clear |
Design Notes
